Ntau -application Growth Chambers – Precision and Versatility
Txhua pawg kuaj lossis cog hauv Achieve Chem Plant Growth Chambers muab cov txiaj ntsig tau meej. Thiab qhov no precision txuas mus raulab (80 - 180 L)thiabindustrial - nplai (txog 2000L)bio- daim ntawv thov kev cog qoob loo. Nyob rau sab saum toj ntawm qhov ntawd, peb cov chav loj hlob ntse tuaj yeem ua kom haum rau ntau hom kev sib txuas thiab tsim kom zoo tagnrhocompound- tej yam kev mob tshwj xeeb. Qhov no ua rau superiorefficiency, zookev loj hlob, thiabrauglab cov txiaj ntsig.
Noj qab nyob zoo thiab zoo -Txoj kev cog qoob loo
Peb Cog Loj Loj Chambers yog tsim los ntawm peb cov flagship Intelligent Artificial Climate Chamber technology. Tsim tshwj xeeb rau kev txhawb nqa kev loj hlob ntawm cov nroj tsuag, cov chav no muaj qhov loj dua, lub teeb pom kev zoo dua rau photosynthesis, ntau yam kev tswj qhov kub thiab txias, thiab ntxiv CO2 fueling system.
Ntsiab Specifications
Laboratory -scale Plant Growth Chamber
|
Qauv |
Muaj peev xwm |
Sab hauv (External) Qhov Loj L × W × H (mm) |
Temperature Range / Fluctuation |
Humidity Range / Fluctuation |
Teeb pom kev zoo |
|
PRX-80A |
80 L |
540×540×350 (590×590×1200) |
0-50℃± 0.5 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-80B |
80 L |
540×540×350 (590×590×1200) |
0-50℃± 0.5 degree |
50-95% RH ± 5% |
12,000 lx |
|
TSW-180A |
180 L |
540×540×650 (590×590×1340) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-180B |
180 L |
540×540×650 (590×590×1340) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
Qauv: PRX-180C |
180 L |
540×540×650 (590×590×1340) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
TSW-180D |
180 L |
540×540×650 (590×590×1340) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
TSW-280A |
280 L |
540×540×960 (590×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-280B |
280 L |
540×540×960 (590×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
Qauv: PRX-280C |
280 L |
540×540×960 (590×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
TSW-280D |
280 L |
540×540×960 (590×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
Pilot-scale Plant Growth Chamber
|
Qauv |
Muaj peev xwm |
Sab hauv (External) Qhov Loj L × W × H (mm) |
Temperature Range / Fluctuation |
Humidity Range / Fluctuation |
Teeb pom kev zoo |
|
Qauv: PRX-380A |
350 L |
540×540×1210 (590×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-380B |
350 L |
540×540×1210 (590×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
Qauv: PRX-380C |
350 L |
540×540×1210 (590×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
Qauv: PRX-380D |
350 L |
540×540×1210 (590×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
PRX-500A |
450 L |
620×620×1150 (680×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-500B |
450 L |
620×620×1150 (680×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
PRX-500C |
450 L |
620×620×1150 (680×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-500D |
450 L |
620×620×1150 (680×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
PRX-600A |
600 L |
1240×540×960 (1300×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-600B |
600 L |
1240×540×960 (1300×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
Qauv: PRX-600C |
600 L |
1240×540×960 (1300×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-600D |
600 L |
1240×540×960 (1300×590×1640) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
PRX-800A |
800 L |
1240×540×1210 (1300×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-800B |
800 L |
1240×540×1210 (1300×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
Qauv: PRX-800C |
800 L |
1240×540×1210 (1300×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-800D |
800 L |
1240×540×1210 (1300×590×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
Industrial-scale Plant Growth Chamber
|
Qauv |
Muaj peev xwm |
Sab hauv (External) Qhov Loj L × W × H (mm) |
Temperature Range / Fluctuation |
Humidity Range / Fluctuation |
Teeb pom kev zoo |
|
PRX-1000A |
1,000 L |
1240×620×1210 (1300×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-1000B |
1,000 L |
1240×620×1210 (1300×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
PRX-1000C |
1,000 L |
1240×620×1210 (1300×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-1000D |
1,000 L |
1240×620×1210 (1300×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
PRX-1200A |
1,200 L |
1800×620×1210 (1860×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-1200B |
1,200 L |
1800×620×1210 (1860×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
PRX-1200C |
1,200 L |
1800×620×1210 (1860×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-1200D |
1,200 L |
1800×620×1210 (1860×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
PRX-1500A |
1,500 L |
1860×620×1210 (1900×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-1500B |
1,500 L |
1860×620×1210 (1900×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
PRX-1500C |
1,500 L |
1860×620×1210 (1900×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-1500D |
1,500 L |
1860×620×1210 (1900×680×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
PRX-2000A |
2,000 L |
2345×705×1145 (2485×765×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
3,000 lx ib |
|
PRX-2000B |
2,000 L |
2345×705×1145 (2485×765×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
12,000 lx |
|
PRX-2000C |
2,000 L |
2345×705×1145 (2485×765×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
22,000 lx |
|
PRX-2000D |
2,000 L |
2345×705×1145 (2485×765×1890) |
0-50℃± 1.0 degree |
50-95% RH ± 5% |
30,000 lx |
|
|
 |
 |
 |
Lus hais
- 600 - 1000 L qauv tuaj nrog aob - qhov rooj configuration
- 1200L thiab siab dua tuaj nrog atriple- qhov rooj configuration
- Txhua tsob nroj loj hlob Chamber yog ntxiv subcategorized rau hauvHom A , Hom B , Hom C, thiabHom Draws li qhov illumination siv.
Nco tseg:Rau cov ntawv tshwj xeeb uas xav tau kev cog qoob loo ntev ntawm qhov kub qis dua 10℃lossis siab dua 40 degree, thiab txheeb ze av noo qis dua 50% RH, peb xav kom kojtham nrog peb cov engineers.
Lab/Industrial Scale Plant Growth Chamber – Cov khoom tseem ceeb
Ib qho khoom siv, ntau yam kev siv
Cov ntawv thov tseem ceeb ntawm peb cov chav muaj xws li cog cov nroj tsuag kev loj hlob, kab lis kev cai ntawm cov ntaub so ntswg, kev cog qoob loo, tsis tshua muaj kab, kev txiav txim siab BOD, thiab kev cog qoob loo tshwj xeeb ntawm cov bios rhiab heev - cov kab mob thiab cov kab mob.
Muaj tseeb Environmental Simulations
Los ntawm automation thiab meej engineering, Achieve Chemcog kev loj hlob Chamber Tuam Tshojtso cai rau koj los tsim kom muaj qhov zoo tshaj plaws kub thiab av noo theem rau kev loj hlob sai nyob rau hauv ib tug luv luv lub sij hawm thiab ntawm ib tug txo nqi peev txheej.
Kev Ua Haujlwm 30-theem
Koj tuaj yeem faib cov txheej txheem cog rau hauv 30 theem sib txawv thiab kho lub sijhawm ntev rau txhua theem. Qhov no yuav pab koj kho qhov kev nyab xeeb hauv cov chav kom haum rau cov kev hloov pauv tshwj xeeb, suav nrog hnub thiab hmo ntuj.
Durable thiab Safety -ua raws sab hauv
Peb siv kev lag luam-raws li stainless hlau rau cov chav sab hauv ntawm peb cov khoom siv cog qoob loo. Qhov no ua rau cov nroj tsuag thiab cov bios rhiab heev - cov tshuaj muaj kev nyab xeeb los ntawm kev sib kis, ua kom cov qoob loo zoo tshaj plaws.
Customizable tswb System
Qhov no yog ib qho kev xaiv uas tso cai rau koj los teeb tsa kev nyab xeeb ntawm cov nroj tsuag loj hlob chamber kub los tiv thaiv cov nroj tsuag los ntawm tshav kub heev. Cov kev khiav hauj lwm nres tam sim ntawd thaum qhov ntsuas kub ntawm qhov kev txwv hla dhau.
Sync txheej txheem soj ntsuam nrog cov ntaub ntawv tsom xam
Nrog lub ntse thiab qib siab RS485 interface, peb cov cuab yeej tso cai rau koj los txuas cov kev soj ntsuam kev sim nrog cov ntaub ntawv kaw, uas txhais tau ntxiv rau kev txheeb xyuas cov ntaub ntawv tsis muaj kev qhia txog cov ntaub ntawv sib txawv.
Modular Tsim
Peb modular Plant Growth Chamber txo tag nrho lub sij hawm downtime los ntawm kev txiav luv luv lub txij nkawm thiab tu lub sij hawm. Kev hloov pauv, kev saib xyuas tsis tu ncua, thiab kev tu ncua sij hawm tsis tas yuav rhuav tshem tag nrho cov cuab yeej, thaum kawg txuag lub sijhawm thiab nqi.
Optimized Resource Siv
Raws li Liebig Txoj Cai Lij Choj Yam tsawg kawg nkaus, cov peev txheej tsawg tshaj plaws hais txog cov txheej txheem cog qoob loo. Yog li, Achieve Chem cov cuab yeej tso cai rau koj los txhim kho txhua qhov kev cog qoob loo hauv txoj kev ua tau zoo tshaj plaws, ua kom cov txiaj ntsig zoo dua ntawm tus nqi qis.
Customize koj cov nroj tsuag loj hlob Chamber
Precision thiab Versatility - Ob lub laj thawj tseem ceeb tom qab xav tau kev kho kom haum
Cov nroj tsuag sib txawv loj hlob sib txawv thiab xav tau ntau haiv neeg ib puag ncig kom pom kev loj hlob. Cov txheej txheem cog qoob loo yog tsim los rau kev siv tus qauv, uas txhais tau hais tias lawv tsis tuaj yeem hloov kho rau cov nroj tsuag - tej yam kev cog qoob loo, ua rau subpar cultivation zoo thiab kev loj hlob ceev. Koj qhov chaw kuaj kab mob cog qoob loo tsis tuaj yeem muab qhov kev txiav txim siab no vim nws tsis tuaj yeem tswj CO2, qhov kub thiab txias, thiab cov av noo nyob rau hauv qhov yuav tsum tau ua thiab tswj kev sib xws rau lub sijhawm ntev.
Customizable Smart Plant Loj hlob Chamber
Achieve Chem qhia txog kev hloov kho txhua qhov chaw uas tsim nyog los xyuas kom meej tias cov nroj tsuag loj hlob chamber specifications ua raws li koj cov kev cai cog qoob loo. Los ntawm qhov ntev ntawm lub chamber loj hlob mus rau qhov kub thiab txias thiab lub tswb nrov, qhov yooj yim ntawm kev hloov kho txuas mus rau txhua qhov tseem ceeb, suav nrog:
- Qhov kub thiab txias
Teem qhov tsawg kawg nkaus thiab siab tshaj plaws kub raws li cov nroj tsuag kev nyab xeeb theem lossis cov kev xav tau ntawm kev sim.
- txheeb ze humidity
Adjustable humidity theem rau tswj cov nroj tsuag transpiration thiab loj hlob tej yam kev mob.
- Lub teeb siv
Customizable illumination theem kom tau raws li cov kev xav tau sib txawv photosynthetic.
- Lub sijhawm yees duab
Programmable teeb / tsaus voj voog rau simulate hnub thiab hmo ntuj.
- CO₂ concentration
Kho tau CO₂ qib rau kev tswj photosynthesis thiab tsob nroj- kev tshawb fawb txog kev loj hlob.
- Chamber qhov ntev
Customized internal ntim thiab usable loj hlob cheeb tsam raws li tus qauv kom muaj nuj nqis.
- Shelving configuration
Adjustable naj npawb, qhov siab, thiab kev npaj ntawm rhawv rau txawv nroj tsuag loj.
- Tswj qhov system
Programmable tswj kub, av noo, teeb pom kev zoo, CO₂, thiab lwm yam kev khiav hauj lwm tsis.
- Tswb nqis
Customizable siab / qis txwv rau qhov kub, av noo, CO₂, thiab lwm yam tsis tseem ceeb.
- Cov ntaub ntawv kaw
Configurable saib xyuas thiab kaw lub sijhawm rau kev sim cov ntaub ntawv.
- Qhov rooj configuration
Ib qho -, ob npaug -, lossis ntau- qhov rooj teeb tsa nyob ntawm qhov nkag mus tau thiab qhov loj ntawm chav.
- Kev nyab xeeb nta
Customizable interlocks, tswb, tshaj- tiv thaiv kub, thiab lwm yam kev tswj kev nyab xeeb.
Vim li cas koom tes nrog Achieve Chem
Kev koom tes nrog cov chaw tsim khoom lag luam uas ntseeg siab, ntseeg tau, xws li Achieve Chem, daws ib nrab ntawm koj cov teeb meem cog qoob loo los ntawm kev qhia cov cuab yeej ntse thiab tsim nyog automation. Nrog 2 cov chaw tsim khoom tau lees paub thoob plaws 279,000 m² thiab 6 ceg, Achieve Chem yog lub chaw tsim khoom thoob ntiaj teb uas muab kev sim thiab kev lag luam - nplai cov kev daws teeb meem thoob plaws cov lag luam tseem ceeb. Nrog 18 xyoo ntawm kev tsim khoom, peb lub tuam txhab muab cov cuab yeej ua tau raws li cov qauv zoo thoob ntiaj teb, txhawb kev kuaj qhov tseeb, kev ruaj ntseg ntau lawm, thiab lub zog- ua haujlwm tau zoo.
Ua tiav Chem Service Highlights
- Lab-scale, pilot-scale, thiab industrial-scale chamber manufacturing peev xwm.
- Customized chamber dimensions, txee, teeb pom kev zoo, thiab tswj configurations.
- Kev soj ntsuam zoo thiab kev soj ntsuam zoo ua ntej xa.
- Kev teeb tsa, commissioning, kev cob qhia neeg ua haujlwm, thiab kev txhawb nqa.
- Tom qab -kev muag khoom, kev daws teeb meem, thiab khoom seem- kev pab cuam.
Daim ntawv thov ntawm tsob nroj loj hlob Chamber
Crop Stress Test
Muab qhov chaw tswj xyuas seb cov nroj tsuag teb li cas rau qhov chaw hnyav thiab nws cuam tshuam rau lawv txoj kev loj hlob tag nrho.
Kev cog qoob loo
Siv rau cov txheej txheem ntawm kev hloov cov nroj tsuag nrog kev tswj tus ntoo khaub lig- pollination los ua ke cov yam ntxwv uas xav tau thiab tshem tawm cov kab mob.
Genetic Engineering
Ib qho tseeb version ntawm kev yug me nyuam, qhov twg cov nroj tsuag tau hloov kho nrog DNA thev naus laus zis rau kev siv cov ntawv kuaj sim.
Crop Physiology
Tso cai rau cov kws tshawb fawb thiab cov kws tshawb fawb los txiav txim siab seb cov nroj tsuag qoob loo ua haujlwm li cas, yam cuam tshuam rau lawv txoj kev loj hlob, thiab lawv teb li cas rau kev hloov pauv ib puag ncig.
Tham nrog peb cov kws tshaj lij rau cov lus qhia txog kev nqis peev ntse
Cov kws tshaj lij cov kev taw qhia thiab cov lus qhia los ntawm Achieve Chem ua ntej nqis peev rau hauv chav kuaj- teev lossis kev lag luam Plant Growth Chamber tau ua pov thawj tias yog qhov hloov pauv kev ua si rau peb cov neeg siv khoom. Txoj kev uas peb cov kws tshaj lij tsim cov chaw cog qoob loo raws li koj qhov kev xav tau tshwj xeeb thiab kev ua haujlwm ua haujlwm txuag tau ntau lub sijhawm, kev siv zog, thiab nyiaj txiag rau koj. Ntxiv rau qhov ntawd, lawv cov kev taw qhia dav dav suav nrog txhua qhov tseem ceeb, suav nrog kev hloov kho, kev ua kom zoo dua qub, thiab tom qab- cov kev pabcuam xa.
Teem caij kev sab laj nrog peb cov kws tshaj lij thiab tau txais kev pom zoo ua haujlwm tseem ceeb los xaiv cov cuab yeej tsim nyog thiab qhov tsim nyog ntawm cov khoom siv customization.
Ua tiav Chem Certifications
 |
 |
 |
 |
FAQs
Lub tsev cog qoob loo yog dab tsi thiab nws ua haujlwm li cas?
Cov nroj tsuag loj hlob Chambers siv rau dab tsi?
Yuav ua li cas ib puag ncig tej yam kev mob yuav tswj tau nyob rau hauv ib tug cog kev loj hlob chamber?
Dab tsi yog qhov txawv ntawm cov nroj tsuag loj hlob chamber thiab lub tsev cog khoom?
Dab tsi kub thiab av noo tuaj yeem ua kom cov nroj tsuag loj hlob tuaj?
Kuv yuav ua li cas thiaj xaiv cov nroj tsuag loj hlob chamber?
Cov nroj tsuag loj hlob tuaj yeem hloov kho?
