Lub tshuab nqus tsev nqus tsev vacuum

Chamber Size thiab Peev Xwm

• Qhov Loj: Ntsuas qhov loj tshaj plaws ntawm cov khoom koj xav tau kom haum rau hauv qhov cub. Xav txog ob qho tib si sab nraud kom ntseeg tau tias nws haum rau koj qhov chaw ua haujlwm thiab qhov ntev ntawm sab hauv kom muaj peev xwm txaus.
• Volume: Lub ntim ntawm lub chamber (feem ntau ntsuas hauv liters) txiav txim siab npaum li cas cov khoom tuaj yeem ua tiav ib txhij. Cov ntim loj dua tsim nyog rau kev ua cov khoom siv, thaum cov khoom me me tuaj yeem muaj zog ntau dua - ua haujlwm tau zoo rau cov khoom me me.

Temperature Range thiab Control

• Kev Ua Haujlwm Kub Kub: Txiav txim siab qhov ntsuas kub uas xav tau rau koj daim ntawv thov. Qee qhov cub muaj qhov kub thiab txias los ntawm ambient mus txog 300℃lossis ntau dua.
• Temperature Control Accuracy: Kev tswj qhov kub thiab txias yog qhov tseem ceeb rau kev ua tiav. Nrhiav qhov cub nrog PID (Proportional-Integral-Derivative) controllers kom raug thiab ruaj khov.
• Temperature Uniformity: Xyuas kom lub qhov cub muab qhov kub zoo sib xws thoob plaws hauv lub chamber kom tsis txhob muaj qhov kub thiab txias.

Lub tshuab nqus tsev thiab muaj peev xwm

• Lub tshuab nqus tsev twj tso kua mis: Hom thiab lub zog ntawm lub tshuab nqus tsev twj tso kua mis cuam tshuam rau qib nqus tsev vacuum thiab lub sijhawm nws yuav siv mus txog qib ntawd. Roj- cov twj kaw tau muaj ntau tab sis yuav tsum tau saib xyuas, thaum lub twj tso kua mis qhuav yog huv dua tab sis tuaj yeem kim dua.
• Nqus Theem: Txiav txim siab qhov tsawg kawg nkaus lub tshuab nqus tsev ( ntsuas hauv Torr lossis mbar) xav tau rau koj cov txheej txheem. Lub tshuab nqus tsev siab dua tej zaum yuav xav tau rau cov khoom me me los yog noo noo- cov ntaub ntawv rhiab heev.
• Leak Detection: Xav txog yog tias lub qhov cub tuaj nrog cov yam ntxwv ntawm cov pa xau kom ntseeg tau tias lub tshuab nqus tsev ruaj khov.

Khoom siv ntawm kev tsim kho

• Chamber Khoom: Stainless hlau yog ib qho kev xaiv nrov rau cov chav tsev vim nws cov corrosion kuj, yooj yim ntawm tu, thiab compatibility nrog ntau yam ntaub ntawv.
• Cov Cuab Yeej Cuab Yeej: Tshawb xyuas cov khoom siv thiab tsim cov khoom cua sov kom ntseeg tau tias lawv tsim nyog rau koj cov txheej txheem (xws li, ceramic heaters rau qhov kub siab).
• Seal Material: Cov khoom siv rau cov ntsaws ruaj ruaj yuav tsum sib haum nrog lub tshuab nqus tsev thiab qhov kub thiab txias.

Programming thiab Automation

• Controllers: Saib rau qhov cub nrog cov tswj kev paub zoo uas tso cai rau koj los teeb tsa thiab saib xyuas qhov kub thiab txias, qib nqus tsev, thiab cov txheej txheem ntau- cov txheej txheem.
• Programmable Profiles: Lub peev xwm rau qhov kev pab cuam kub thiab lub tshuab nqus tsev profiles tuaj yeem ua kom cov txheej txheem nyuaj, txo cov neeg ua haujlwm cuam tshuam thiab txhim kho kev tsim tawm.
• Kev tswj chaw taws teeb thiab saib xyuas: Xav txog seb qhov chaw taws teeb nkag lossis kev sib txuas lus tseem ceeb rau koj txoj haujlwm.

Kev nyab xeeb nta

• Tshaj -Kev Tiv Thaiv Kub: Xyuas kom lub qhov cub muaj dhau- tiv thaiv qhov kub kom tsis txhob muaj kev puas tsuaj rau cov qauv lossis qhov cub nws tus kheej.
• Nqus Relief Valve: Lub tshuab nqus tsev vacuum valve tiv thaiv kev tsim siab ntau dhau - thaum lub zog tsis ua haujlwm lossis cov khoom siv tsis raug.
• Cov ntawv pov thawj: Tshawb xyuas cov ntawv pov thawj kev nyab xeeb, xws li CE lossis UL, nyob ntawm koj qhov chaw nyob.

Nqi thiab Warranty

• Kev nqis peev pib: Sib piv cov nqi sib txawv ntawm cov qauv thiab hom, suav nrog cov yam ntxwv, qhov zoo, thiab cov nqi ntev -.
• Cov Nqi Kho Mob: Xav txog cov nqi ntawm cov khoom siv, cov khoom seem, thiab cov kev pabcuam tu.
• Warranty: Saib rau qhov cub nrog qhov kev lees paub dav dav uas npog cov khoom thiab kev ua haujlwm.

Chamber Material (Inner Plhaub)

• Stainless hlau (Qib 304 los yog 316L): Cov qib stainless hlau no feem ntau siv rau sab hauv chamber vim lawv tshwj xeeb corrosion kuj, siab kub kam rau ua, thiab yooj yim ntawm tu. Lawv tiv thaiv kev sib kis ntawm cov qauv thiab xyuas kom lub qhov cub kom ntev.
• Aluminium nrog Txheej (yog tias tsim nyog): Hauv qee daim ntawv thov tshwj xeeb uas txo qhov hnyav yog qhov tseem ceeb, txhuas siv tau nrog cov txheej tiv thaiv los txhim kho corrosion thiab tswj qhov kub thiab txias.

Cov khoom siv rwb thaiv tsev

• Fiberglass los yog Ceramic Fiber Rwb thaiv tsev: Cov ntaub ntawv no muab cov thermal rwb thaiv tsev zoo heev, txo qis cua sov thiab tso cai rau cua sov thiab cua txias. Lawv kuj yog lub teeb yuag thiab tiv taus qhov kub thiab txias, ua kom lub zog ua haujlwm zoo thiab txo cov nqi khiav lag luam.

Qhov rooj thiab qhov rai khoom

• Tempered Glass lossis Quartz Window: Lub qhov rooj feem ntau muaj lub qhov rais pob tshab uas ua los ntawm cov iav tempered los yog quartz rau kev saib xyuas cov qauv yam tsis tau ua txhaum lub tshuab nqus tsev. Quartz yog qhov zoo dua rau kev siv kub heev vim nws cov thermal stability ntau dua.
• Stainless Hlau Qhov Rooj Ncej: Txhim kho nrog cov hlau tsis muaj steel, lub qhov rooj thav duab ua kom muaj kev ncaj ncees thiab kev sib khi kom nruj kom tswj tau lub tshuab nqus tsev hauv chamber.

Sealing Khoom

• Siab -Tub kub Silicone los yog Fluoropolymers: Lub tshuab nqus tsev- cov ntsaws ruaj ruaj nyob ib ncig ntawm lub qhov rooj thiab tej zaum cov ntsiab lus xau feem ntau yog ua los ntawm cov ntaub ntawv zoo li silicone los yog fluoropolymers uas tuaj yeem tiv taus qhov kub thiab txias thiab tuav lub foob zoo txawm tias nyob hauv lub tshuab nqus tsev.

Cov Cuab Yeej Cuab Yeej

• Nickel-Chromium Hlau lossis Incoloy Sheathed Elements: Cov khoom cua sov no tau xaiv rau lawv cov kev ua haujlwm siab rau oxidation, muaj peev xwm kub kub, thiab siv tau ntev. Lawv ua kom sov lub chamber rau qhov xav tau qhov kub thiab txias.

Lub tshuab nqus tsev twj txuas thiab cov khoom siv

• Stainless hlau fittings thiab li qub: Txhawm rau kom muaj kev huv huv ntawm lub tshuab nqus tsev, cov khoom siv stainless hlau thiab cov li qub yog siv los txuas lub qhov cub rau lub tshuab nqus tsev twj. Lawv yog cov corrosion-resistant thiab haum rau tuav cov pa phem los yog reactive gases.

Tswj vaj huam sib luag thiab Electronics

• Plastic los yog Hlau Enclosure: Lub vaj huam sib luag tswj, vaj tse nyob rau hauv qhov kub thiab txias controllers, timers, thiab cov lus qhia, yog ua los ntawm cov khoom siv ruaj khov uas tuaj yeem tiv taus qhov chaw nyob ze ntawm qhov cub. Qee cov qauv zoo tshaj plaws muaj cov ntxaij vab tshaus kov hauv cov khoom tawg - iav tiv taus.
